Wafer Pattern Ball Valve, PN1.6-2.5 Mpa
Key Specifications / Features
Model No.: Hits: 64
China Wafer Pattern Ball Valve Manufacturer Shinjo Supplies Wafer Pattern Ball Valve, PN1.6-2.5 Mpa.
Request a quote
Share
Tags:
Detail Information
Design Standards:
DIN 2501 / DIN 2526
PN10/16/25, ANSI B16.5, EN 1092-1
Feautres:
Full port, sizes 1/2'' to 8''.
Temperature to 366°F.
Blow out proof stem, adjustable stem packing.
PTFE. seats, packing and thrust washer.
Space-saving design.
DIN 2501 / DIN 2526
PN10/16/25, ANSI B16.5, EN 1092-1
Feautres:
Full port, sizes 1/2'' to 8''.
Temperature to 366°F.
Blow out proof stem, adjustable stem packing.
PTFE. seats, packing and thrust washer.
Space-saving design.
| NO. | PART | MATERIAL | |
| STAINLESS STEEL | CARBON STEEL | ||
| 1 | BODY | CF8M/ CF8 | WCB |
| 2 | BALL | SS316/304 | SS304 |
| 3 | GASKET | PTFE | PTFE |
| 4 | STEM | SS316/304 | SS304 |
| 5 | STEM PACKING | PTFE | PTFE |
| 6 | COCATELOCK | SS304 | SS304 |
| 7 | HANDLE | SS304 | SS304 |
| 8 | STEM NUT | SS304 | SS304 |
| 9 | GLAND NUT | SS304 | SS304 |
| 10 | HANDLE COVER | PLASTIC | PLASTIC |
| 11 | SEAL BOTTLE CAP | SS316/304 | SS304 |
| 12 | WASHER | PTFE | PTFE |
| SIZE | 1/2” | 3/4” | 1” | 11/4” | 11/2” | 2” | 21/2” | 3” | 4” | 5” | 6” |
| d | 15 | 19 | 23.5 | 30 | 36 | 45 | 58 | 67 | 76 | 100 | 125 |
| L | 32 | 38.5 | 45 | 55 | 62 | 72 | 95 | 120 | 145 | 200 | 225 |
| D | 95 | 105 | 115 | 135 | 145 | 160 | 180 | 195 | 215 | 245 | 280 |
| D1 | 65 | 75 | 85 | 100 | 110 | 125 | 145 | 160 | 180 | 210 | 240 |
| D2 | 45 | 55 | 65 | 78 | 85 | 100 | 120 | 135 | 155 | 185 | 210 |
| H | 62 | 70 | 79 | 86 | 92 | 102 | 158 | 172 | 187 | 200 | 240 |
| E | 110 | 125 | 135 | 150 | 150 | 180 | 250 | 300 | 350 | 650 | 840 |
| b | 14 | 14 | 16 | 16 | 18 | 20 | 22 | 24 | 24 | 26 | 26 |
| z-d1 | 4-14 | 4-14 | 4-14 | 4-18 | 4-18 | 4-18 | 4-18 | 8-18 | 8-18 | 8-18 | 8-23 |
| f | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
