Short Description

Model No.: SJ-VP-01 Hits: 5

China Water Ring Vacuum Pump Supplier Offers Water Ring Vacuum Pump, Single-stage Liquid Ring Vacuum Pump, 27 m3/h - 500 m3/h, Also Suitable for Oil.
Request a quote Share

Key Specifications / Features

Overview
A 2BV series water ring vacuum pump is suitable for pump air with water vapor, inspiratory pressure can reach 33mbar absolute pressure (97% vacuum degree). When the pump works under the inspiratory pressure closed to limit vacuum (work fluid saturation vapor pressure) for a long time, it should be connected to a cavitation protecting tube, in order to protect the pump. When working as the compressor, the greatest pressure is up to 0.26 MPa (absolute pressure).

As a new generation energy-saving product, with its excellent performance and numerous advantages, 2BV series water ring vacuum pumps will fully replace SK, 2SK series water ring vacuum pumps and W, WY, WL series reciprocating pumps.

Main Features
1. Direct coupling design, save space, easy to install and convenient maintenance.
2. All equipped with cavitation protection tube, if works under limit work pressure, open cavitation protection tube (or with separator connection) can maximum guarantee inspiratory effect under the condition of cavitation, and protect the pump.
3. 2BV series can be equipped with stainless steel impeller, high strength and durability, and improves the corrosion resistance of the pump.
4. Unique flexible air outlet design, won't produce over compression, ensure its performance efficiency is the best.
5. All adopt Y2 series motor, IP54\IP55 protection (ordinary, IP44), insulation class F (ordinary is class B insulation).
6. The flexible seal can be completely PTFE, which can greatly extend pump service life under harsh conditions.

water-ring-vacuum-pump-single-stage-27-m3-h-500-m3-h-1

water-ring-vacuum-pump-single-stage-27-m3-h-500-m3-h-1

Code Model Max. Capacity Limit Pre. mbar(MPa) Power kW Ex. Grade Protect. G Speed r. p. m Water Flow L/min dB(A) W( kg)
m3/min m3/h
60V 2BV2 060 0.45 27










33mbar
(-0.098MPa)

0.81

N/A


IP54
2840 2 62 31
61V 2BV2 061 0.86 52 1.45 2840 2 65 35
70V 2BV2 070 1.33 80 2.35 2860 2.5 66 56
71V 2BV2 071 1.83 110 3.85 2880 4.2 72 65
60V 2BV2 060-Ex 0.45 27 1.1

dIIBT4


IP55
2840 2 62 39
61V 2BV2 061-Ex 0.86 52 1.5 2840 2 65 45
70V 2BV2 070-Ex 1.33 80 3 2860 2.5 66 66
71V 2BV2 071-Ex 1.83 110 4 2880 4.2 72 77
110V 2BV5 110 2.75 165 4


N/A



      IP54
1440 6.7 63 103
111V 2BV5 111 3.83 230 5.5 1440 8.3 68 117
121V 2BV5 121 4.66 280 7.5 1440 10 69 149
131V 2BV5 131 6.66 400 11 1460 15 73 205
161V 2BV5 161 8.33 500 15 970 20 74 331
110V 2BV6 110 2.75 165 4


dIIBT4



IP55
1440 6.7 63 153
111V 2BV6 111 3.83 230 5.5 1440 8.3 68 208
121V 2BV6 121 4.66 280 7.5 1440 10 69 240
131V 2BV6 131 6.66 400 11 1460 15 73 320
161V 2BV6 161 8.33 500 15 970 20 74 446
